2017 New Style Brake Lathe - Surface Grinder Machine MY1230 – Hoton Detail:

HYDRAULIC SURFACE GRINDING MACHINE

1.Hydraulic longitudinal table travel

2.Quality castings and Precision ball bearing supporting the spindle

3.Coolant system with nozzle and flow control valve

4.Cast iron machine body and stand for maximum rigidity and smooth operation

5.Vertical dial graduations 0.01mm

6.Cross travel graduations 0.02mm

7.Manual one shot lubrication pump

8.Wheel balancing stand and arbor

9.Halogen work light

SPECIFICATIONS:

MODEL		UNIT	MY1230
Table Size		mm	750×300
Max.longitudinal travel of the table		mm	780×320
Max.area to be ground		mm	780×310
Max.distance of table surface to spindle center		mm	550
Slide-way of Table			Double V-type rail
The Speed of Longitudinal travel		m/min	3-20
Feed of Cross Handwheel	per revolution	mm	2.5
	per graduation		0.02
The Speed of cross travel	Off and On	mm/min	1-20
	Continual		50-500
Feed of Vertical Handwheel	per revolution	mm	2
	per graduation		0.01
The Speed of Vertical Travel		mm /min	600
Wheel Speed		50HZ	1450
Wheel Size WA46K5V			250×25.4×76.2
Power of Spindle motor		Kw	2.2
Hydraulic station motor		Kw	2.25
Working Pressure		Mpa	4
Max.Runoff		L/min	20
The Capacity of Fuel Tank		L	100
Coolant Pump		W	40
Net weight of Machine		kg	1400
Gross weight		kg	1530
Machine Size		M	1.88×1.48×1.85
Packing Size		M	1.91×1.50×2.03

Product detail pictures:
