Best Price for Radial Drilling Machine - Rotary Table TSA SERIES – Hoton Detail:

TSA SERIES ROTARY TABLE FEATURES:

1.TSA series rotary table is one of the most important accessory of milling machine.
2.It is widely used for index boring, milling, circle cutting, circle curve plane and segment etc operation.
3.As a option, different table supply different flange, flange will be packed separately. Otherwise, dividing plates which provides from the option can indexing all of the integer between 2 and 66 also can indexing the numbers between 67 and 132 which can be divided exactly by number 2,3 and 5.
4.A flange for connecting scroll chuck is special supplied,and be packed independent.For special order,the dividing plates accessory allows the operator to accurately divide the 360 degree rotation of the clamping surface into divisions of 2 through 66,and all divisible of 2,3 and 5 from 67-132.
5.OPTIONAL ACCESSORIES:hole plate,flange

SPECIFICATIONS:

SPECIFICATION	TS160A	TS200A	TS250A	TS320A	TS400A	TS500A	TS630A	TS800A	TS1000A
Table diameter mm	Φ160	φ200	φ250	φ320	φ400	φ500	φ630	φ800	φ1000
Morse taper of the center hole	2#	3#		4#		5#		6#
width of the T-slot mm	10	12		14		18		22
Adjacent angle of table T-slot	90°		60°			45°
Width of the locating key mm	12	14		18		--	--	--	--
Graduation of the table	360°
Minimum value of vernier	10"
Indexing accuracy	80"	60"
Max workload kg	100	150	200	250	300	550	700	1200	2000
Net weight Kg	16.5	22.5	33.5	65	125	215	345	800	1300
Gross weight Kg	21.5	31	44.5	76	145	238	377	855	1400
Case dimensions mm	400x330x200	400x360x208	500x400x210	580x480x238	750x616x280	850x730x302	995x900x326	1175x1090x391	1430x1224x550

INSTALLATION SKETCH AND DIMENSION:

MODEL	TS160A	TS200A		TS250A	TS320A	TS400A			TS500A	TS630A		TS800A	TS1000A
A	260	290		330	410	530			640	820		1000	1170
B	196	236		286	360	450			560	700		890	1080
C	332	369		422	493	612			753	898		1080	1295
D	160	ø200		ø250	ø320	ø400			ø500	ø630		ø800	ø1000
G	12	14			18				22			22	-
H	75	80	90		110		140		158.5	160		215	250
J	12	14			18				22			30	-
K	76	91.25	102.5		128.5			180	230		295	364	364
L	194	211	241		273			337	393		468	535	654
M	MT2	MT3			MT4				MT5			MT6
P	27	27	30.5		44			60	65	68		76		106
Q	125							160	180	220		250
d	ø25	ø30			ø40				ø50			ø75
h	6	10			12				14
