Affordable Pneumatic Forging Hammer JGWG-70 & JGWG-70C by Hoton

Cheapest Price Pneumatic Forging Hammer - Metal Craft Machines JGWG-70 JGWG-70C – Hoton

Short Description:

METAL CRAFT PIPE BENDER FEATURES: The JGWG Series Metalcraft Pipe Bender, designed by our company, is a motor-driven tool set for special purposes. By utilizing the metal materials’ adaptable distortion, the tool can bend metal pipes into patterns in the shape of arcs. The machine, a necessity for today’s ornamental industry, can be widely used in such fields as architecture, decoration, furnishing and municipal gardening. The tool can be operated by pressing individual components and can sim...

Send email to us Download as PDF

Product Detail

Product Tags

Feedback (2)

With our great management, potent technical capability and strict excellent handle procedure, we continue on to provide our customers with reputable top quality, reasonable selling prices and great providers. We purpose at becoming amongst your most trusted partners and earning your satisfaction for Bench Milling Drilling Machine , Horizontal Cnc Turning Lathe , Cnc Slotter Machine , We feel that a passionate, ground breaking and well-trained workforce can create fantastic and mutually useful business associations with you quickly. Be sure to really feel totally free to contact us for more particulars.

Cheapest Price Pneumatic Forging Hammer - Metal Craft Machines JGWG-70 JGWG-70C – Hoton Detail:

METAL CRAFT PIPE BENDER FEATURES:

The JGWG Series Metalcraft Pipe Bender, designed by our company, is a motor-driven tool set for special purposes. By utilizing the metal materials’ adaptable distortion, the tool can bend metal pipes into patterns in the shape of arcs. The machine, a necessity for today’s ornamental industry, can be widely used in such fields as architecture, decoration, furnishing and municipal gardening. The tool can be operated by pressing individual components and can simultaneously be operated semi-automatically under control of optical-electric code system, suitable for mass production. Such striking features as simplicity in structure, easy to operate, energy-saving and highly efficient make the tool ideal for pipe bending.

1. Motor drive pipe bender.
2. semi--automatically for mass production
3. DRO for bending angle showing.
4. Suitable for hard material using.
5. Hydraulic type is available for model "C"

SPECIFICATIONS:

SPECIFICATIONS		JGWG-40	JGWG-70
Bending capability	Round pipe	¢40x2.5	¢70x4.5
Bending capability	Square Pipe	40X40X2	50X50X3
Bending Angle	Degree	<180	<180
Output rotational speed of main shaft	r/min	11	10
Main motor power	kw	3	4
Packing Size	cm	94X62X113	135X78X114
Net weight	kgs	380	770
Gross weight	kgs	428	840

ITEM	JGWG-40C		JGWG-70C
Max. Size of Processing Materials	Round Pipe	φ40	φ70
	Square Tube	40x40x1	50x50x1
Bending Angle	<180°
Rotating Speed of the Main Shaft (r/min)	Rotational Speed(r/min)	1.2	1.2
Functions of the Motor	Power(KW)	3	5
	Rotational Speed(r/min)	1400	1400
	Voltage(V)	415 (as per customer's request )
	Frequency (HZ)	50(as per customer's request )
Hydraulic Special motor	Power (KW)	2.2
	Rotational Speed (r/min)	1400
	Voltage (V)	220/380
	Frequency(HZ)	50
External Size(LxWxH)mm	950x760x1000	1300x700x900
Packing Size(LxWxH)mm	1050x860x1100	1350x800x1200
Net Weight ( kg)	400	860
Gross Weight ( kg)	450	900

Product detail pictures:
