China New Product Mini Lathe Machine - Universal Tool Milling Machine X8126C – Hoton Detail:

UNIVERSAL TOOL MILLING MACHINE FEATURES
1. Original structure, broad versatility, high accuracy, easy to operate.
2. With various attachments to extend range of application and raise utilization.
3. Model XS8126C: With Programmable digital display system, resolving power is up to 0.01mm.

SPECIFICATIONS:

MODEL		X8126B/X8126C
Worktable area		280x700mm
Distance between axis of horizontal spindle to table	First installing position	35---385mm
	Second installing position	42---392mm
	Third installing position	132---482mm
Distance between vertical spindle nose to horizontal spindle axis		95mm
Distance between horizontal spindle nose to vertical spindle axis		131mm
Transverse travel of horizontal spindle		200mm
Vertical travel of vertical spindle quill		80mm
Range of horizontal spindle speeds(8 steps)		110---1230rmp
Range of vertical spindle speeds(8 steps)		150---1660rmp
Spindle hole taper		ISO40/Morse No.4
Swivel angle of vertical spindle axis		±45°
Longitudinal/vertical travel of table		350mm
Feeds of table in longitudinal, and vertical directions and horizontal spindle seat in transverse direction		25---285mm/min
Rapid travel of table in longitudinal and vertical directions		1000mm/min
Main motor		3kw
Coolant pump motor		0.04kw
Overall dimension		1450x1450x1650
Net/gross weight		1180/2100
Overall packing dimension		1700x1270x1980
