UNIVERSAL CYLINDRICAL GRINDING MACHINE FEATURES:
1) Universal
2) Precise
3) With high rigidity
4) Reliable performance
SPECIFICATIONS:
|
MODEL |
UNIT |
SPECIFICATIONS |
|||
|
M1432B×1000 |
M1432B×1500 |
M1432B×2000 |
M1432B×3000 |
||
|
General capacity |
|||||
|
Distance between centers |
mm |
1000 |
1500 |
2000 |
3000 |
|
Center height |
mm |
180 |
180 |
180 |
180 |
|
Dia.Ground(O.D) |
mm |
8~320 |
8~320 |
8~320 |
8~320 |
|
Dia.Ground(I.D) |
mm |
30~100 |
30~100 |
30~100 |
30~100 |
|
Max.length ground(O.D) |
mm |
1000 |
1500 |
2000 |
3000 |
|
Max.length ground(I.D) |
mm |
125 |
125 |
125 |
125 |
|
Max weight of work piece |
kg |
150 |
150 |
150 |
150 |
|
Workhead |
|||||
|
Swiveling angle |
+90 |
+90 |
+90 |
+90 |
|
|
Center taper |
MT |
4 |
4 |
4 |
4 |
|
Spindle speed |
r/min |
50HZ:25-220 |
50HZ:25-220 |
50HZ:25-220 |
50HZ:25-220 |
|
Wheelhead |
|||||
|
Wheel spindle speed |
r/min |
1670 |
1670 |
1670 |
1670 |
|
Wheelhead rapid travel |
mm |
50 |
50 |
50 |
50 |
|
Max travel |
mm |
246 |
246 |
205 |
205 |
|
Swiveling angle |
° |
±30° |
±30° |
+10° |
+10° |
|
Hand feed per.rev |
mm |
rough:2.0 |
rough:2.0 |
rough:2.0 |
rough:2.0 |
|
Hand feed per.gra |
mm |
rough:0.01 |
rough:0.01 |
rough:0.01 |
rough:0.01 |
|
Max dimension of wheel(OD×W×ID) |
mm |
400×50×203 |
400×50×203 |
400×50×203 |
400×50×203 |
|
Internal grinding |
|||||
|
Spindle speed |
r/min |
10000/15000 |
10000/15000 |
10000/15000 |
10000/15000 |
|
Dimension of wheel |
mm |
max:50×25×13 |
max:50×25×13 |
max:30×25×10 |
max:30×25×10 |
|
Table |
|||||
|
Hand feed per rev. |
mm |
6 |
6 |
6 |
6 |
|
Max swivelling angle of table |
° |
clockwise:3° |
clockwise:3° |
clockwise:2° |
clockwise:2° |
|
Longitudinal traverse speed of table |
m/min |
0.1~4 |
0.1~4 |
0.1~4 |
0.1~4 |
|
Tailstock |
|||||
|
Center taper |
MT |
4 |
4 |
4 |
4 |
|
Quill travel |
mm |
30 |
30 |
30 |
30 |
|
Motor |
|||||
|
Wheelhead motor power |
Kw |
5.5 |
5.5 |
5.5 |
5.5 |
|
Internal grinding |
Kw |
1.1 |
1.1 |
1.1 |
1.1 |
|
Power of workhead motor |
Kw |
1.5 |
1.5 |
1.5 |
1.5 |
|
Machine |
|||||
|
Gross weigh |
Kg |
5300 |
6100 |
7900 |
9900 |
|
Packing dimension |
mm |
3220×2000×2050 |
4220×2000×2050 |
5400×2000×2050 |
7390×2280×2050 |
