Short Description:

T7220C is mainly used to bore high accurate holes of cylinder body and engines sleeve and other accurate holes. It can used for milling surface of cylinder.The machine can be used for boring,milling,drilling,reaming The table longitudinal and cross moving device; The workpiece fast centering device; Boring measuring device; Also provides optional digital readout for the table's longitudinal and cross moving accessories to serve the users. Model T7220C Max. boring Diameter Φ200mm Max. B...

Send email to us Download as PDF

Product Detail

Product Tags

Feedback (2)

Sticking towards the principle of "Super High-quality, Satisfactory service" ,We've been striving to become a superb business partner of you for Zx45 Drilling Milling Machine , Bench Lathe , Bandsaw Gh4250 , We welcome new and previous customers from all walks of lifestyle to contact us for long run organization relationships and mutual achievements.

factory low price Universal Gear Hobbing Machine - Vertical Boring Machine T7220C – Hoton Detail:

The table longitudinal and cross moving device;

The workpiece fast centering device;

Boring measuring device;

Also provides optional digital readout for the table's longitudinal and cross moving accessories to serve the users.

Model		T7220C
Max. boring Diameter		Φ200mm
Max. Boring Depth		500mm
Milling cutter-head diameter		250/315mm
Spindle Speed Range		53-840rev/min
Spindle Feed Range		0.05-0.20mm/rev
Distance from Spindle Axis to Carriage Vertical plane		315mm
Table Longitudinal Travel		1100mm
Table longitudinal feed speed		55̖̖̖110mm/min
Table longitudinal quick move speed		1500mm/min
Table cross travel		100mm
Machining accuracy	Boring Dimension Accuracy	IT7
	Milling dimension accuracy	IT8
	Roundness	0.005
	Cylindricity	0.02/300
Boring roughness		Ra1.6μm
Milling roughness		Ra1.6~3.2μm
Overall Dimensions(L×W×H)		2610×1655×2345mm
N.W/G.W		3800/4200kg
Packing dimensions(L×W×H)		1830×1964×2535mm

Product detail pictures:
