High definition Lathe C6251 - CNC SINGLE PIPE BENDING MACHINE DW25/38/50/63/75/89 CNC-2A-1S – Hoton Detail:

CNC PIPE BENDER PROPERTIES:

Automatic identification of dynamic characteristics of machine tool/work piece-rapid and good processing；

Return the core and boost with trolley--improve the appearance of corner piece.

The Chinese operation prompts+15 inch true color display+ touch screen-sipple and clear operation.

The graphical programming system:the processing procedure can be obtained upon the vertical tube painting system/modification on the screen-simple,convenient,rapid and accurate programming.

Resilience measurement-the property of batches of pipes can be compared and measured.

Single-step debugging function-the deformation process of pipes is observed closely during mould trial-manufacture.

Automatic mould drawing--help significantly develop new products.

Comprehensive monitoring:Hydraulic/electrical/drive system,motor phase loss/reversal,voltage,temperature,oil pressure,automatic fault diagnosis,passwords,key.records of working hours/number,for production management.

Model		DW25CN-2A-1S	DW38CN-2A-1S	DW50CN-2A-1S	DW63CN-2A-1S
Min bending R for carbon pipe is:1.5D		∅25.1×1.6t	∅38.1×2.0t	∅50.8×2.0t	∅63.5×2.0t
Max feed distance		1300mm	2100mm	2400mm	2500mm
Feeding method		Servo motor
Max R for bending		175mm	175mm	250mm	250mm
Max angle for bending		185°	185°	185°	185°
Bending process for every pipe		16	16	16	16
Max bending group		200	200	200	200
Working rate	Bending Rate	Max.45m/s	Max.45m/s	Max.40m/s	Max.35m/s
	Rotary Rate	Max.270m/s	Max.270m/s	Max.270m/s	Max.270m/s
	Feeding Rate	Max700m/s	Max700m/s	Max700m/s	Max700m/s
Working Accuracy	Bending Angle	±0.15°	±0.15°	±0.15°	±0.15°
	Rotary Angle	±0.1°	±0.1°	±0.1°	±0.1°
	Feeding Angle	±0.1mm	±0.1mm	±0.1mm	±0.1mm
Data Input Method		Working value(Y.B.C)	Working value(Y.B.C)	Working value(Y.B.C)	Working value(Y.B.C)
Rotary Servo motor Power		400W	850w	850w	850w
Feeding Servo motor Power		750W	1300w	1300w	1300w
Electric Motor Power		4KW	4kw	5.5kw	5.5kw
Weight		1000kg	2100kg	2500kg	2800kg
Machine Size		250×60×120	380×100×130	430×90×130	430×90×140

Model		DW75CN-2A-1S	DW89CN-2A-1S
Min bending R for carbon pipe is:1.5D		∅76.2×2.0t	∅88.9×2.0t
Max feed distance		2800mm	3000mm
Feeding method		Servo motor
Max R for bending		175mm	250mm
Max angle for bending		185°	185°
Bending process for every pipe		16	16
Max bending group		200	200
Working rate	Bending Rate	Max.30m/s	Max.25m/s
	Rotary Rate	Max.180m/s	Max.180m/s
	Feeding Rate	Max600m/s	Max600m/s
Working Accuracy	Bending Angle	±0.15°	±0.15°
	Rotary Angle	±0.1°	±0.1°
	Feeding Angle	±0.1mm	±0.1mm
Data Input Method		Working value(Y.B.C)	Working value(Y.B.C)
Rotary Servo motor Power		1300W	1300w
Feeding Servo motor Power		2000W	2000w
Electric Motor Power		7.5KW	11kw
Weight		3600kg	3800kg
Machine Size		510×120×140	530×120×140

Product detail pictures:
