High-Quality Turret Milling Machine X6332C from Hoton Manufacturer

High Quality for Tube Turn - Turret Milling Machine X6332C – Hoton

Short Description:

TURRET MILLING MACHINE FEATURE: 1.TAIWAN milling head 2.Rectangular and dovetail guideway can available 3.Worktable travel of X-axis up to 800mm 4.Saddle becomes bigger SPECIFICATIONS SPECIFICATIONS X6332C Table size mm 1250X320 Table travel 800X300X350MM Number/Width/Distance of T-slot 3/14/70 Distance between spindle nose and table surface 150-500MM Distance between spindle axis and column surface 150-550 MM Spindle travel 150MM Spindle taper(V...

Send email to us Download as PDF

Product Detail

Product Tags

Feedback (2)

We have now a skilled, performance group to offer excellent support for our consumer. We usually follow the tenet of customer-oriented, details-focused for Radial Drilling Machine , Vertical Turret Milling Machine , Surface Grinder Machine , Created solutions with brand price. We attend seriously to produce and behave with integrity, and because of the favor of clients in your own home and overseas in the xxx industry.

High Quality for Tube Turn - Turret Milling Machine X6332C – Hoton Detail:

TURRET MILLING MACHINE FEATURE:

1.TAIWAN milling head

2.Rectangular and dovetail guideway can available

3.Worktable travel of X-axis up to 800mm

4.Saddle becomes bigger

SPECIFICATIONS

SPECIFICATIONS	X6332C
Table size mm	1250X320
Table travel	800X300X350MM
Number/Width/Distance of T-slot	3/14/70
Distance between spindle nose and table surface	150-500MM
Distance between spindle axis and column surface	150-550 MM
Spindle travel	150MM
Spindle taper(V/H)	7:24 ISO40
Spindle speed range RPM	63-5817(V)60-1350(H)
Spindle motor power	3.7(V)2.2(H) KW
Overall dimension	1720X1520X2225 MM
Machine weight	1770/1900KGS

Product detail pictures:
