VERTICAL DRILLING MILLING MACHINE
Compound sliding table with scale and adjustable stops for coordinate drilling and light milling work
Quiet operation with oil-bath lubricated gears for long tool life and durability
The milling machine's high-quality spindle bearing can withstand higher loads for the long term
Manual drill feed can be switched to high-precision feed via a hand-wheel
Controllable automatic feed with 3 gear steps
Adjustable height of gear head and table
Table guides are adjustable with high precision via taper gibs
Gear head swivels to both sides
Cutter mounts are secured by an M16 draw bar
Tapping feature
Integrated coolant system
SPECIFICATIONS:
|
ITEM |
Z5032C |
Z5040C |
Z5045C |
|
Max.drilling capacity |
32mm |
40mm |
45mm |
|
Spindle taper |
M.T.3 or R8 |
M.T.4 |
M.T.4 |
|
Spindle travel |
130mm |
130mm |
130mm |
|
Step of spindle speed |
6 |
6 |
6 |
|
Range of spindle speed 50Hz |
80-1250 r.p.m |
80-1250 r.p.m |
80-1250 r.p.m |
|
60Hz |
95-1500 r.p.m |
95-1500 r.p.m |
95-1500 r.p.m |
|
Min.distance from spindle axis to column |
283mm |
283mm |
283mm |
|
Max.distance from spindle nose to worktable |
700mm |
700mm |
700mm |
|
Max.distance from spindle nose to stand table |
1125mm |
1125mm |
1125mm |
|
Max.travel of headstock |
250mm |
250mm |
250mm |
|
Swivel angle of headstock (horizontal /perpendicular) |
360°/±90° |
360°/±90° |
360°/±90° |
|
Max.travel of worktable bracket |
600mm |
600mm |
600mm |
|
Table size |
730×210mm |
730×210mm |
730×210mm |
|
Size of stand worktable of available |
417×416mm |
417×416mm |
417×416mm |
|
Forward and afterward travel of worktable |
205mm |
205mm |
205mm |
|
Left and right travel of worktable |
500mm |
500mm |
500mm |
|
Vertical travel of worktable |
570mm |
570mm |
570mm |
|
Motor Power |
0.75kw |
1.1kw |
1.5kw |
|
speed of motor |
1400rpm |
1400rpm |
1400rpm |
|
Net weight/Gross weight |
430/500kg |
432/502kg |
435/505kg |
|
Packing size |
1850x750x 1000mm |
1850x750x 1000mm |
1850x750x 1000mm |
