CNC Lathe TCK6350 & Milling Machines XK6323A, XK6325, XK6330

Wholesale Cnc Lathe Tck6350 - CNC Turret Milling Machine XK6323A and XK6325 and XK6330 – Hoton

Short Description:

The guide way on saddle is lined with TF wearable material The worktable surface and 3 axis guide way are hardened and precision ground Model Unit XK6323A XK6325 XK6330 Table size mm 230*1067 254*1270 305*1370 T slot 3*16*65 Table loading kg 200 280 350 X axis (table longitudinal move) travel mm 550 750 800 Y axis (table cross move) travel mm 300 400 360 Z axis (Quill move) travel mm 127 X/Y/Z axis rapid feed mm/min 5000 X/Y/Z axis servo motor kw 1 Knee vertical ...

Send email to us Download as PDF

Product Detail

Product Tags

Feedback (2)

"Sincerity, Innovation, Rigorousness, and Efficiency" would be the persistent conception of our enterprise with the long-term to build with each other with consumers for mutual reciprocity and mutual advantage for Grinder Sga4080 , Brake Lathe , Cnc Lathe Machine , We will supply best quality, the most market competitive price, for every new and old customers with the most perfect green services.

Wholesale Cnc Lathe Tck6350 - CNC Turret Milling Machine XK6323A and XK6325 and XK6330 – Hoton Detail:

The guide way on saddle is lined with TF wearable material
The worktable surface and 3 axis guide way are hardened and precision ground

Model			Unit	XK6323A	XK6325	XK6330
Table size			mm	230*1067	254*1270	305*1370
T slot				31665
Table loading			kg	200	280	350
X axis (table longitudinal move) travel			mm	550	750	800
Y axis (table cross move) travel			mm	300	400	360
Z axis (Quill move) travel			mm	127
X/Y/Z axis rapid feed			mm/min	5000
X/Y/Z axis servo motor			kw	1
Knee vertical travel			mm	380	400	410
Ram travel			mm	315	465	500
Distance from spindle to table			mm	0-380	0-400	0-410
Milling head	Spindle speed		rpm	50HZ:60-4500/60HZ:80-5440 16steps
	Spindle taper			Standard:R8		ISO40
	Motor Power		HP	3		5
	Head rotating	Swiveling		90°
		Tilting		90°
CNC control system				Simens 808D
Package size			cm	165190220	190200223	200200225
G.W.			kg	1200	1700	1800

Product detail pictures:
