Factory wholesale Machining Centre Mill 850 - Bench Lathe CJM280 – Hoton Detail:

METAL SMALL LATHE MACHINE FEATURES:
Precision ground and hardened bed ways.
The spindle is supported with precision roller bearings.
Headstock gears are made of high quality steel, ground and hardened.
Easy operating speed change levers.
Spindle speed range 90-800rpm.Easy operating gear box has various feeds and thread cutting function.
With or without cabinet according to requirement.
SPECIFICATIONS:

MODEL	CJM280
Swing over bed	280 mm
Center distance	500 mm	750mm
Swing over carriage	160 mm
Spindle bore	38 mm
Spindle taper	MT.5#
Swing over toolpost	140 mm
Longitudinal travel over toolpost	75 mm
Metric thread available	18
Metric thread range	0.20~3.5 mm
Inch thread available	34
Inch thread range	41/2~48 1/n″
Module thread available	16
Module thread range	0.20~1.75
Pitch thread available	24
Pitch thread range	16~120 /DP
Longitudinal feed on spindle toolpost	0.08~0.56 mm/r
Cross feed on spindle toolpost	0.04~0.28 mm/r
Tailstock sleeve travel	60 mm
Tailstock sleeve taper	MT.3#
Spindle speed step	8
Spindle speed range	90~1800 r/mim
Motor	750W 380V 50HZ (220V 50HZ)
Packing size	1450×650×1200	1200×650×1200
