High Quality Small Gear Hobbing Machine Y3150 - CNC Gantry Milling Machine X2012 – Hoton Detail:

Specification			Unit	X2010	X2012	X2014
Max. travel	Length	mm	2000/3000/4000
	Width	mm	1300	1400	1800
	Height	mm	1000	1000/1200
Distance between columns			mm	1440	1600	1920
Table size	Length	mm	2000/3000/4000
	Width	mm	1000	1250	1400
Table feeding speed	Feed	mm/min	20-360	25-450
	Rapid travel	mm/min	1050	1300
Spindle taper				7:24, ISO50
Spindle speed step			r/min	6steps 82-505
Spindle swivel angle				±35°
Feed rate of milling head			mm	Along the cross rail:65/320/890Side milling head:50/265/730
Power of spindle motor			kw	7.5
Power of table motor			kw	4/5.5/7.5	5.5/7.5(3000/4000)
Overall size	Length	mm	4550/7000/9000	5000/7000/9000
	Width	mm	3200	3550
	Height	mm	2550	2950/3150

Product detail pictures:
