Low MOQ for Mini Milling Machine - Surface Grinder Machine M818A – Hoton Detail:

Specifications		Units	M618A	M818A
Table Size		mm	460×180	450x210
Max.work piece to be ground		mm	500×190×335	470x220x350
Max. grinding length		mm	500	470
Max. grinding width		mm	190	220
Distance from table to spindle		mm	335	450
Slide way			V-type rail with Steel-ball
V-type rail with steel-ball		kg	200
Number of T -slot		mm×n	12×1	12x1
Speed of working table		m/min	3-23	3-23
Cross feed on handwheel		mm	0.02/Graduation 2.5/revolution
Vertical feed on handwheel		mm	0.01/Graduation 1.25/revolution
Wheel size (dia.×width×bore )		mm	200×16×31.75	200x13x31.75
Spindle Speeds	50Hz	rpm	2850	2850
Spindle Speeds	60HZ	rpm	0-6000	3450
Spindle motor		Kw	1.1	1.5
Coolant pump		Kw	0.4	0.5
Machine size (L×W×H)		mm	1550×1060×1590	1330x1150x1675
Packing size (L×W×H)		mm	1060×1170×1870	1400x1120x1985
Machine weight		T	0.75/0.65	0.8

Product detail pictures:
